Su-34 (Su-32) Fullback Fighter Bomber

Su-34 fighter bomber, also known as Su-27IB, was developed by the Sukhoi Design Bureau Joint Stock Company, Moscow and the Novosibirsk Aircraft Production Association at Novosibirsk, Russia.

Crew
Two
Length
23.34m
Height
6.36m
Wingspan
14.05m
Normal Take-Off Weight
39,999kg
Maximum Take-Off Weight
45,100kg
Normal Combat Load Weight
4,000kg
Maximum Combat Load Weight
8,000lg
Fuel, Internal Tanks
12,100kg
Fuel, External Tanks
19,300kg
Maximum Low-Altitude Speed
1,300km/h
Maximum High-Altitude Speed
1,900km/h
Service Ceiling
14,000m
Take-Off Run
1,260m
Landing Run
2,100m
Landing Run With Brake parachute
950m
Maximum g-Load
7g
Range Near Ground Radius of Action, 900km/h, Normal Combat Load, Internal Fuel Tanks
600km
Range Near Ground Radius of Action, 900km/h, Normal Combat Load, External Fuel Tanks
1,130km
Ferry Range With External Fuel Tanks
4,500km
Gun
1 x GSh-301
Ammunition
180 rounds
Firing Rate
1,500 rounds a minute
Missiles
R-73 short-range air-to-air missile
High-presision autonomous air-to-surface missiles
Air-to-air missiles, target designation for air-to-air missiles
Guided air-to-surface missiles
Anti-radiation missiles
Air-to-ship missiles
Controlled and guided aerial bombs
Unguided bombs and rockets
Maximum Launch Weight
105kg
Warhead
7.3kg, rod type
Guidance
Cooled infrared
Length
2.9m
Diameter
0.17m
Fin Span
0.51m
Maximum Launch Range
20km
Minimum Range of Aft Hemisphere Launch
300m
Target Acceleration g-Load
12g
Kill Probability Fighter Target
0.6
Maximum Target Speed
2,500km/h
Target Altitudes
0.02km to 20km
Launch Weight
175kg
Warhead
21kg, rod type
Guidance
Active radar homing
Radio-corrected inertial navigation for on-trajectory target lock-on
Missile Retargeting
Length
3.6m
Diameter
0.2m
Fin Span
0.75m
Maximum Target Speed
3,600km/h
Target Acceleration g-Load
12g
Kill Probability Fighter Target
0.7
Target Altitudes
0.02km to 25km
Minimum Range of Aft Hemisphere Launch
300m
Maximum Vertical Separation of Target and Host Aircraft
10km

Su-34 fighter bomber, also known as Su-27IB, was developed by the Sukhoi Design Bureau Joint Stock Company, Moscow and the Novosibirsk Aircraft Production Association at Novosibirsk, Russia.

The Su-34, which replaces the Tu-23M and Su-24 aircraft, has been in service with the Russian Armed Forces since 2014. It is one of the derivatives of the Su-27 Flanker, apart from the Su-30, Su-33 and Su-35.

The Su-34 design retains the basic layout and construction of the Su-27 airframe along with conventional high-wing configuration and onboard equipment.

Orders and deliveries

The Russian Air Force ordered an initial 32 Su-34 aircraft in 2008, with an additional requirement for 92 aircraft in 2012. The first two production aircraft were delivered to the Russian Air Force in December 2006. The export designation of the Su-34 is Su-32.

Full-rate production began in January 2008. In the same month, the Russian Air Force stated that 70 aircraft would be secured by 2015.

Under a state contract with the Russian Ministry of Defence, Sukhoi will deliver the Su-34 bombers to the Russian Air Force and army units until 2020.

The Russian Air Force received two Su-34 aircraft in December 2009. Four more Su-34 fighter-bombers were provided in December 2010.

Sukhoi’s Novosibirsk aircraft plant handed over another two Su-34s in December 2011. Five Su-34 aircraft were supplied in December 2012.

The company also delivered five Su-34 frontline bombers to the Russian Air Force in January 2013, and a batch of Su-34 frontline bombers were distributed in October 2013.

Sukhoi transferred the final consignment of Su-34 front-line bombers to the Russian Air Force in December 2013, concluding the five-year state contract signed in 2008.

Under the 2014 State Defence order, Sukhoi released the first set of serial Su-34 frontline bombers to the Russian Air Force in June 2014. The second batch was delivered in July 2014 and a further delivery of Su-34 bombers was made in October 2014. An additional two bombers were handed over in December 2014.

Under the 2015 state defence order, Sukhoi provided the first two batches of Su-34 aircraft to the Russian Ministry of Defence (MoD) in May 2015.

An additional batch of Su-34 bombers was delivered to the MoD in November 2015. The firm concluded the 2015 state defence order with the delivery of two aircraft in December 2015.

Following the 2016 state defence order, Sukhoi handed over three batches of Su-34 frontline bombers to the Russian Air Force in 2016.

Sukhoi Aircraft’s parent company United Aircraft was awarded a contract by the Russian MoD in December 2019, for supplying modernised variant Su-34M.

Russia’s Defense Ministry inked a three-year contract with Sukhoi Aircraft in June 2020 for 20 Sukhoi Su-34 frontline bombers with certain modifications.

Su-34 design and cockpit

The Su-34, however, has a changed contour of the nose section to accommodate an advanced, multi-mode, phased array radar with terrain following and terrain avoidance modes.

It has a two-seat rather than single-seat cockpit and capacity of the internal fuel tanks has been increased with a resulting increased take-off weight. Changes have been made to the central tail boom for rear-facing radar.

The cockpit has two K-36DM zero/zero ejection seats side-by-side for the pilot and co-pilot. The seats are supplied by Zvesda Research and Production Enterprise Joint Stock Company, Moscow. The multifunction displays in the cockpit show the flight parameters, the operational status of the aircraft units, and tactical data.

Weapons onboard the Su-34

The Su-34 is armed with a 30mm GSh-301 gun and 180 rounds of ammunition. The gun has a maximum rate of fire of 1,500 rounds a minute and the muzzle velocity is 860m/s. It is supplied by the Instrument Design Bureau, Tula.

The aircraft has ten hardpoints for weapon payloads and is able to carry a range of missiles, including air-to-air, air-to-surface, anti-ship and anti-radiation missiles, guided and unguided bombs, and rockets. The aircraft is fitted with a target designator.

The R-73, Nato codename AA-11 Archer, short-range, air-to-air missile is supplied by the Vympel State Engineering Design Bureau, Moscow. The R-73 is an all-aspect missile capable of engaging targets in tail-chase or head-on mode. The missile has cooled infrared homing.

The R-73 attacks the target within target designation angles of ±45° and with angular rates up to 60° a second. The missile can intercept targets at altitudes between 0.02km and 20km, and target G-load to 12g, with target speeds of up to 2,500km/h.

Also known as the RR-77 or by the Nato designation AA-12, the RVV-AE long-range air-to-air missile is manufactured by Vympel. The missile can intercept targets at speeds up to 3,600km/h and altitudes from 0.02km to 25km. The minimum range in the aft hemisphere is 300m and the maximum vertical separation between the host aircraft and the target is 10km.

The RR-77 has inertial guidance with mid-course radio updates and terminal active guidance. A new, longer-range (150km) version of the R-77, with solid fuel ram-jet propulsion, is being tested by Vympel.

The Su-34 carries a range of precision-guided and unguided bombs and rockets, including the KAB-500 laser-guided bomb developed by the Region State Research and Production Enterprise, Moscow.

Systems of the Su-34

The Su-34 is equipped with an electro-optical fire control system, supplied by the Urals Optical and Mechanical Plant (YOM3), and a Geofizika FLIR pod, with forward-looking infrared. Leninetz of St Petersburg supplies the passive phased array radar system and TsNIRTI the electronic countermeasures suite.

Engines and performance

First production aircraft are powered by two after-burning NPO Saturn AL-31F turbofan engines. Later aircraft may be fitted with MMPP Salyut AL-31F-M2/3 or NPO Saturn 117 engines. They are mounted under the wing and are equipped with all-duty fixed geometry air intakes. A rotor protection installed in the air intakes provides protection against the ingestion of foreign objects.

Internally, the aircraft can carry 12,100kg of fuel in two fuel tanks in the wings and four in the fuselage. Three external 3,000l fuel tanks can also be fitted.

The aircraft can achieve a speed of 1,900km/h (Mach 1.6) at altitude and 1,300km/h (Mach 1) at sea level, and has a flight range of 4,000km.
