Scale model of a GBU-38 mounted on a sting, positioned above a B-52 scale model in transonic wind tunnel at Arnold Air Force Base, Tennessee, US. Credit: U.S. Air Force photo by Jill Pickett.

Organisations from the US Air Force Test Center (AFTC) have evaluated B-52H Stratofortress’ capability to release a GBU-38 bomb with new load configurations.

The test was executed by Air Force Seek Eagle Office (AFSEO), under 96th Test Wing, Eglin Air Force Base (AFB) and Store Separation Section, Arnold Engineering Development Complex, Arnold AFB.

Go deeper with GlobalData

Premium Insights

The gold standard of business intelligence.

Find out more

Related Company Profiles

View all

Aligned under AFTC, both the organisations used their expertise to test B-52H capability to release GBU-38 with multiple load configurations on heavy stores adapter beam (HSAB) in a 16ft transonic wind tunnel at Arnold AFB.

GBU-38 is a 500lb BLU-111/MK82 unguided free-fall bomb with joint direct attack munition (JDAM) guidance tail kit.

Conducting a ground test in wind tunnel allowed test personnel to control various conditions, including temperature, speed and altitude, crucial for gathering required data for a portion of flight envelope.

See Also:

Besides, the store separation testing allowed measuring the forces and moments of test article, using strain gauges on a balance, while positioning the store in three ways, including pseudo-freestream, grid and trajectory.

How well do you really know your competitors?

Access the most comprehensive Company Profiles on the market, powered by GlobalData. Save hours of research. Gain competitive edge.

Company Profile – free sample

Thank you!

Your download email will arrive shortly

Not ready to buy yet? Download a free sample

We are confident about the unique quality of our Company Profiles. However, we want you to make the most beneficial decision for your business, so we offer a free sample that you can download by submitting the below form

By GlobalData
Visit our Privacy Policy for more information about our services, how we may use, process and share your personal data, including information of your rights in respect of your personal data and how you can unsubscribe from future marketing communications. Our services are intended for corporate subscribers and you warrant that the email address submitted is your corporate email address.

Aerodynamics Test Branch test manager Austin Stewart said: “The test used pseudo-freestream positioning where store was placed far away from parent aircraft and then data at a large range of pitch and yaw angles was taken to determine forces and moments acting on store when it was exposed to tunnel air without interference from parent aircraft.

“Grid data was taken at increments along a line stepping away from release point of store on HSAB.

“This allowed interference of B-52H aircraft on store to be characterised. Trajectory data was taken on a closed-loop system.”

This test, according to AFTC, investigated interference flow fields generated by neighbouring stores, including GBU-31 precision-guided munition, CBU-87 dispenser and MK64 ER air-launched mine.
