F-35 JSF aircraft

Raytheon has successfully conducted a fit check of its GBU-53/B small diameter bomb II (SDB II) onboard a US Air Force (USAF) F-35 joint strike fighter (JSF) aircraft.

During the testing, which was carried out at an undisclosed location, a total of four SDB II shapes were loaded, along with an advanced medium range air-to-air missile (AMRAAM) into the aircraft’s weapon bay.

Go deeper with GlobalData

Premium Insights

The gold standard of business intelligence.

Find out more

The sweeps of the inboard and outboard bay doors successfully confirmed adequate clearance between the two weapons.

Raytheon Missile Systems Air Warfare System vice president Harry Schulte said the fit check completion is critical, as it further evaluates SDB II’s compatibility with the F-35 and also keeps it on track for a smooth transition to production.

"Once fielded, SDB II will provide the warfighter with an unprecedented capability to precisely strike moving targets in adverse weather conditions and through battlefield obscurants," Schulte added.

See Also:

"The sweeps of the inboard and outboard bay doors successfully confirmed adequate clearance between the two weapons."

The bomb, currently in production, has already demonstrated its target tracking and destruction capabilities, while operating from the USAF’s F-15E fighter jet during a testing at White Sands Missile Range in New Mexico, US, in July 2012.

How well do you really know your competitors?

Access the most comprehensive Company Profiles on the market, powered by GlobalData. Save hours of research. Gain competitive edge.

Company Profile – free sample

Thank you!

Your download email will arrive shortly

Not ready to buy yet? Download a free sample

We are confident about the unique quality of our Company Profiles. However, we want you to make the most beneficial decision for your business, so we offer a free sample that you can download by submitting the below form

By GlobalData
Visit our Privacy Policy for more information about our services, how we may use, process and share your personal data, including information of your rights in respect of your personal data and how you can unsubscribe from future marketing communications. Our services are intended for corporate subscribers and you warrant that the email address submitted is your corporate email address.

Equipped with an improved tri-mode seeker including millimetre-wave radar, uncooled imaging infrared and semi active laser and a highly lethal warhead, the SDB II is an air-launched precision-strike weapon, designed to destroy armoured targets from stand-off ranges in adverse weather conditions, with minimum collateral damage.

Currently in the engineering and manufacturing development phase, the bomb is designed to be installed on F-15E, F-35B and F-35C aircraft, and also shows compatibility with the USAF F-35A, F/A-22 and F-16C/D, as well as the Navy F/A-18E/F Super Hornet fighter jet.

The bomb is expected to be delivered to the air force in 2013.

Image: The F-35 JSF aircraft supported the GBU-53/B SDB II fit check.
