B-2 AESA antenna

Northrop Grumman’s new active electronically scanned array (AESA) antenna being developed for the US Air Force’s (USAF) B-2 Spirit bomber has demonstrated its ability to establish and maintain communications with an on-orbit advanced extremely high-frequency (AEHF) satellite system.

The demonstration was carried out at an undisclosed location using the antenna, a navy multi-band terminal and the satellite, and represents a significant step taken by the company towards reducing the risks and costs associated with development of an EHF satellite communications system for the bomber.

The company successfully demonstrated extended data rate (XDR) communications between the AESA antenna and the AEHF satellite at EHF frequencies during testing.

Northrop Grumman B-2 deputy programme manager Byron Chong said the demonstration marks the first time use of AESA antenna technology for communication with the AEHF network.

"We showed that our antenna will consistently produce and maintain the high-gain beam needed to communicate with AEHF satellites," Chong stated.

Featuring a no radome design, the AESA antenna is designed to support both B-2’s tactical and strategic missions through the addition of new communications capabilities, while maintaining its major operational characteristics.

How well do you really know your competitors?

Access the most comprehensive Company Profiles on the market, powered by GlobalData. Save hours of research. Gain competitive edge.

Company Profile – free sample

Thank you!

Your download email will arrive shortly

Not ready to buy yet? Download a free sample

We are confident about the unique quality of our Company Profiles. However, we want you to make the most beneficial decision for your business, so we offer a free sample that you can download by submitting the below form

By GlobalData
Visit our Privacy Policy for more information about our services, how we may use, process and share your personal data, including information of your rights in respect of your personal data and how you can unsubscribe from future marketing communications. Our services are intended for corporate subscribers and you warrant that the email address submitted is your corporate email address.
"The EHF satellite is expected to enable the bomber to relay and receive battlefield information at significantly faster data rates compared with the existing satellite communications system."

The EHF satellite is expected to enable the bomber to relay and receive battlefield information at significantly faster data rates compared with the existing satellite communications system.

Northrop has also evaluated the antenna’s performance over its entire transmit and receive frequency band, and over its required range of scan angles at its Space Park facility in Redondo Beach, US, in May this year.

Powered by four General Electric F118-GE-100 non-afterburning turbofan engines, the B-2 Spirit is a low-observable, strategic, long-range, heavy bomber designed to penetrate complex air-defence shields and deploy conventional and nuclear weapons.

Serving as the B-2 prime contractor, Northrop leads an industry team that will upgrade the aircraft to ensure it reaches full operational readiness against evolving worldwide threats.


Image: Northrop engineers measuring RF power levels of the transmit array of the new antenna prior to its demonstration. Photo: courtesy of Northrop Grumman.
